Description
This AC EV charging station provides a safe, reliable, and user-friendly charging solution for electric vehicles. Designed with industrial-grade principles, the unit consists of a lightweight charging body, wall-hanging mounting backboard, and an optional floor pedestal stand.
Key Features & Highlights:
Vibrant 7″ LCD Display: Equipped with a 7-inch color screen, live status LED indicators (Red/Green/Blue), current adjustment buttons, and delay reservation controls.
Flexible Start Modes: Supports RFID card swipe, plug & play, or mobile App control for effortless operation.
Advanced Electrical Safety: Integrated Type B leakage protection (RCD 30mA AC + 6mA DC), ST MCU chipset, surge protection, ground protection, over/under voltage, over/under frequency, and over-temperature defense.
Weatherproof & Flame Retardant: IP65-rated for complete dust and water resistance, suitable for harsh outdoor sun, rain, and wind exposure.
High-Quality Build: Pure copper wiring without oxidation, certified flame-retardant materials, and high impact resistance.
Global Safety Certifications: Certified under CE (EN61851), UKCA, RoHS, TUV, and CB international standards.
Technical Data | |||
| EV charging modes | Mode 3 Charging | ||
| Power supply | 1P+N+PE | 3P+N+PE | 3P+N+PE |
| Rated voltage | 230VAC -1Phase | 400VAC -3Phase | 400VAC -3Phase |
| Rated power | 7KW | 11KW | 22KW |
| Rated current | 32A | 16A | 32A |
| Rated frequency | 50/60Hz | ||
| Over voltage category (OVC) | OVC III | ||
| Insulation resistance | R > 1 MΩ | ||
| Protection against electric shock | Class I | ||
| Electrical life (Contactor) | 100,000 | ||
| Electrical life (Interface) | 100,000 | ||
| Standby power consumption | < 8W | ||
| Type of EV connection | Case B (Socket version) / Case C (Cable version) | ||
| Universal interface | T1: SAE J1772, T2: IEC/EN 62196-2, GB/T: 20234.2-2015 | ||
| Support protocol | Modbus-RTU | ||
| Functional | DLB, LED, LCD, RFID | ||
| Protection | RCD-DD DC6mA; Over temperature protection | ||
| Pollution degree | PD 3 | ||
| IP protection class | IP65 | ||
| Altitude during operation (m) | < 2000m | ||
| Altitude of test laboratory | < 50m | ||
| Work humidity | 5%~95% | ||
| Operation temperature | -30°C~50°C | ||
| Cooling | Natural air cooling | ||
| Mounting method | Wallmounted | ||
| Normal environmental conditions | Indoor use; Outdoor use |
